Tunnels and Viaducts on the A51 Motorway in Italy, by Kilometre Point
Tunnel / Viaduct	Direction San Donato M.se	Direction Usmate	Notes
			Connection A1 Milano - Bologna, Connection A50 Tangenziale Ovest; Reg. Lombardy – Prov. MI
			Exit 1 – San Donato Milanese
San Donato	853 m	853 m
			Exit 2 - SS 9 Via Emilia
			Exit 3 - SS415 - Paullo - MM3 San Donato
			Exit 4 - Via Mecenate
			Exit 5 - C.A.M.M.
Dei Parchi	2 896 m	3 342 m
			Exit 6- Linate Airport – V.le Forlanini (on viaduct)
			Exit 7 - Via Rubattino (on viaduct)
			Exit 8 - Lambrate - SP103 Rivoltana
	Agip	Agip	Service Areas "Cascina Gobba"
			Exit 9 – Via Padova - Gobba MM2
			Exit 10 – Via Palmanova
	-		Connection A52 Tangenziale Nord Sesto S.G. - Paderno D.
			Exit 11 - Cologno Monzese Sud
			Exit 12 – Cologno Monzese Nord
	-	Totalerg	Service Area "Cologno Est"
			Exit 13 – Cernusco / Brugherio SP 113
			Exit 14 - Carugate
	Tamoil	Tamoil	Service Areas "Carugate"
			Toll barrier Agrate
			Connection A4 Torino - Trieste
			Exit 15 - Agrate
			Exit 16 – Monza SP13 - Custom Concorezzo
		-	Exit 17 - Concorezzo
			Exit 18 – Burago SP 200
			Exit 19 – Vimercate Sud
			Exit 20 – Arcore - Villasanta SP 45
		-	Exit 21 – Vimercate Centro
Vimercate I	150 m	150 m
Vimercate II	800 m	800 m
			Exit 22 – Vimercate Nord
			Exit 23 – Carnate SP 117
			Exit 24 – Usmate Velate Sud
	Agip	-	Service Area "Vimercate Ovest"
			Connection SS 342 dir
TOTAL tunnel	950	950
